Kona Unity

$2,699.00
Available to Order
Ultimate bikepacking rig!
Color
Size
Out of stock, available for pre-order
Product Details
Brand: Kona Bicycle Company

Bikepacking has evolved and its enthusiasts have cried out—in its echo, a new Kona has burst onto the scene: the Unity. It might be the ultimate utilitarian bike, but it would be rude to put it in just one box. It’s a mountain bike. It’s a gravel bike. It’s a bikepacking mule and a burly beast of burden built to go further, deeper, and more rugged than most bikes dare.

We wanted big tires. And mixed wheels! Trendy? Maybe. But we chose MX because it brings the center of gravity where we want it, makes a stronger rear wheel, and allows for more clearance when it comes to rear racks and seat bags.

We wanted BIGGER LOADS, but weren’t willing to sacrifice ride quality. So, we optimized the geometry for riding under load, dialing in fork offset and handling to stay predictable when you’re fully packed.

With a custom integrated cargo rack up front and an oversized front triangle built for max frame bag space, the Unity is ready for your biggest missions.

Whether you’re riding across a mountain range or building an off-grid battle cruiser, the Unity has your back—and your front.

SPECIFICATIONS

FRAME Kona Butted Cromoly
SIZES S, M, L, XL
FORK Kona Cromoly
CRANKSET RaceFace Aeffect Cinch 28t / S 165mm / M-L 170mm / XL 175mm
BOTTOM BRACKET RaceFace BSA 73
PEDALS Kona JS2
CHAIN KMC eGlide Turbo
CASSETTE Shimano XT 11-50t 11spd
CHAINGUIDE n/a
FRONT DERAILLEUR n/a
REAR DERAILLEUR Shimano XT
SHIFTER Shimano XT
BRAKE CALIPERS Tektro Gemini M535 4-piston
FRONT BRAKE ROTOR Tektro 203mm 6B 2.3mm
REAR BRAKE ROTOR Tektro 203mm 6B 2.3mm
BRAKE LEVERS Tektro Gemini M535
HEADSET FSA No.10 ZS44/ZS44
HANDLEBAR Kona 31.8mm / Back 9º / Up 5º / Rise 15mm / Width 780mm
STEM Kona 31.8mm / Rise 0º / Length S-M 35mm / M-L 45mm
SEATPOST Kona Thumb w/Offset 31.6mm / 375mm
SEAT CLAMP Kona Clamp 34.9mm
GRIPS Kona Key Grip Lock-on
SADDLE WTB Volt Medium
FRONT HUB DT Swiss 370 15x110mm
REAR HUB DT Swiss 370 12x148mm HG
SPOKES Stainless 2.0mm Black
FRONT RIM WTB KOM i40 Tough 29"
REAR RIM WTB KOM i40 Tough 27.5"
FRONT TIRE WTB Ranger TCS Tough 29x3.0"
REAR TIRE WTB Ranger TCS Tough 27.5x3.0"
PAINT COLOR Gloss Future Dusk w/ Blackcurrant, Nectarine, Wisteria & Pale Moss Decals
EXTRAS Kona Unity Front Rack 6061 Aluminum
All specifications are subject to change without notice.
Prerelease products may be displayed as graphic representations.

GEOMETRY

Size S M L XL
1 ST Length 370 420 470 530
2 TT Length 591 623 656 691
3 Reach 435 460 485 510
4 Stack 615 620 629 643
5 Standover 725 760 816 849
6 HT Angle 65.8 65.8 65.8 65.8
7 HT Length 160 165 175 190
8 ST Angle 75.8 75.3 74.8 74.3
9 CS Length 440-456 440-456 440-456 440-456
10 BB Drop 70 70 70 70
11 BB Height 311 311 311 311
12 Wheelbase 1176-1191 1203-1219 1232-1248 1263-1279
13 Front Center 745 772 796 831
14 Fork Length 450 450 450 450
15 Fork Offset 59 59 59 59
